Conversion Instructions for PEGAsys
P/N 06-237058-001 H-3 February 2012
H-3 OPTIONAL PARTS (NOT INCLUDED IN RETROFIT KIT)
H-3.1 Parts for the Control Unit Bottom Tier
One of the following optional equipment may be added to the bottom tier of the retrofitted control
unit, if desired. (Exception: See Note below regarding batteries.)
1. Card Cage with backplane, bracket and hardware kit with cables, P/N 76-800010-001
2. Standby Batteries (select one pair from list below)
3. Add-on Power Supply/PMU Assembly with bracket and hardware, P/N 76-800030-003
Note: If the Card Cage will be installed in the retrofitted control unit, it is possible to fit a 7-AH or
12-AH battery pair inside the enclosure. However, the 17/18-AH battery pair will NOT fit in
a retrofitted control unit which includes a Card Cage.
Installation instructions for these parts are provided in this manual in Chapter 2, Installation, or
refer to the individual instructions packaged with the equipment.
H-3.2 Additional ARIES NETLink Parts
In some cases, it may be necessary to order additional parts for complete ARIES NETLink
functionality. For example, if the retrofitted control unit includes the Card Cage, ARIES NETLink
expansion cards must be ordered and installed. Older PEGAsys expansion cards will not work in an
ARIES NETLink system.
STANDBY BATTERIES (order 2 for 24V)
06-115915-013 Battery, 12 Vdc, 7-AH
06-115915-047 Battery, 12 Vdc,12-AH
06-115915-046 Battery, 12 Vdc, 17/18-AH
