Kidde Fire Systems ARIES NETLink User Manual

Conversion Instructions for PEGAsys
February 2012 H-2 P/N 06-237058-001
Expansion Power Supply,
5.4A, with wiring harness to
PMU Board
(P/N 76-800030-002)
1
Power Management (PMU)
Board
(P/N 76-800030-004)
1
Main Controller Board with
Keypad/Display and
mounting hardware
(P/N 76-800020-001)
1
MCB Installation Hardware
Kit
(P/N 06-220294-001)
1 package
• cable assembly (1)
• ground wire assembly (1)
• aluminum standoffs (4)
• 8/32” screws (4)
• EOL 10K resistors (5)
PMU Installation Hardware
Kit
(P/N 06-220293-001)
1 package
• cable assemblies (3)
• ground wire assembly (1)
• battery harness kit (1)
• 8/32” screws (6)
• PMU term.block cover (1)
• aluminum standoff (1)
•4-position plug (2)
•2-position plug (1)
Installation/Configuration Kit
(P/N 76-800000-008)
1 package
• wiring diagram on paper (1)
• User Disk (1)
Part Name
Quantity
Provided
Illustration
