August 2013 3-28 P/N 06-236530-001
3-2.5.2.3.17 How to View the Configurable Parameters for the Control Unit’s On-
Board Outputs
Purpose: To determine how the control unit’s on-board outputs are
programmed.
Step Action Result
1 Press 0 Key Initiate Menu Access
2 Enter Password; press "Enter" Key Gain access to menus
3 Press 2 Key Enter List-Menu branch
4 Press "Scroll" Key twice Access additional options
5 Press 9 Key Access "More Options" option
6 Press 1 Key Access “Onboard Circuits” option
7 Press 1 Key for NACs, or
Press 2 Key for Release Circuits, or
Press 3 Key for Combo Circuits, or
Press 4 Key for Programmable Relays
Select on-board output type
8 Enter on-board output number View output's configurable parameters
9 Press "Backspace" Key, and repeat Step 8 View another output of the type selected in Step 7
10 Press "Backspace" Key twice, and repeat Steps 7
and 8
View another output type
11 Press "Backspace" Key (as required) Exit Menu System
