3-2.5.2.3.18 How to List the Remote Display Modules Connected to this Control Unit
Purpose: To view the list of remote-display modules connected to a
ARIES Control Unit
3-2.5.2.3.19 How to View the PSU Statu of Remote Release Modules
Purpose: To get diagnostic information concerning the power supply
unit status of RRM modules. Contact Kidde Technical Support if RRM
units are not functioning properly.
Step Action Result
1 Press 0 Key Initiate menu access
2 Enter Password; Press “Enter” Key Gain access to menus
3 Press 2 Key Enter List-Menu branch
4 Press "Scroll" Key twice Access additional options
5 Press 9 Key Access "More Options"
6 Press 2 Key Select “Control Modules”
7 Press 1 Key for ATM or
Press 2 Key for RDCM.
Press "Enter" Key to confirm selection.
Select display modules to view
8 Press "Scroll" Key (as required) Move through list of selected modules
9 Press "Backspace" Key (as required) Exit Menu System
Step Action Result
1 Press 0 Key Initiate menu access
2 Enter Password; Press “Enter” Key Gain access to menus
3 Press 2 Key Enter Set-Menu branch
4 Press "Scroll" Key twice Access additional options
5 Press 9 Key Select "More Options”
6 Press 5 Key Select “RRM PSU Status”
7 Use keypad to enter single module or range of
modules
Press "Enter" Key to confirm selection.
Specify the RRM modules to view
8 Press "Backspace" Key (as required) Exit Menu System
