P/N 06-236530-001 3-61 August 2013
3-2.5.2.4.40 How to Configure the Control Unit for Central-Station Operation
Purpose: To allocate the programmable relays for off-premises signal
transmission to a central station. Programmable Relay No. 1 is
automatically configured to activate for any alarm condition, and
Programmable Relay No. 2 is automatically configured to activate for
any supervisory condition. Refer to Appendix F.
3-2.5.2.4.41 How to Configure the Global Alarm Acknowledge
Purpose: When this feature is enabled, when the operator presses the
“Acknowledge” key, all current alarms are acknowledged. If this
feature is disabled, the operator must acknowledge each alarm
individually.
Step Action Result
1 Press 0 Key Initiate Menu Access
2 Enter Password; press "Enter" Key Gain access to menus
3 Press 3 Key Enter Set-Menu branch
4 Press "Scroll" Key Access additional Set-Menu options
5 Press 5 Key Select "Globals" option
6 Press "Scroll" Key Access additional Globals-Menu options
7 Press 4 Key Select "Central Station" option
8 Press 1 Key, then press "Enter" Key to confirm
selection.
Activate Central-Station option
9 Press "Backspace" Key (as required) Exit Menu System
Step Action Result
1 Press 0 Key Initiate Menu Access
2 Enter Password; press "Enter" Key Gain access to menus
3 Press 3 Key Enter Set-Menu branch
4 Press "Scroll" Key Access additional Se-Menu options
5 Press 5 Key Select "Globals" option
6 Press "Scroll" Key Access additional Globals-Menu options
7 Press 5 Key Select "Global Alarm Ack" option
8 Press 1 Key to turn on Global Alarm
Acknowledgement or
Press 2 Key to turn off Global Alarm
Acknowledgement,
then press "Enter" Key to confirm selection.
Activate or Deactivate Global Alarm Acknowledge
option
9 Press "Backspace" Key (as required) Exit Menu System
