3-2.5.2.4.42 How to Configure Networked Control Units for Style-7 Communications
Purpose: To enable networked control units to utilize the redundant
communications channel (Channel 2) for Style-7 operation.
Step Action Result
1 Press 0 Key Initiate menu access
2 Enter Password Gain access to menus
3 Press 3 Key Enter Set-Menu branch
4 Press "Scroll" Key Access additional options
5 Press 6 Key Select "Network" option
6 Press 1 Key Select “Style” option
7 Press one of the following:
1 Key
2 Key
3 Key
Selects Channel 1
Selects Channel 2
Selects both Channel 1 and 2
8 Press 1 Key Enable channel(s) selected in Step 7
9 Press "Enter" Key to confirm enabling selection. Selected channel(s) enabled
10 Press "Backspace" Key (as required) Exit Menu System
11 Wait until "Initializing Configuration" message
disappears from the display.
Initialization complete
