3-2.5.2.4.43 How to Disable Style-7 Communications for Networked Control Units
Purpose: To prevent networked control units from utilizing the
redundant communications channel (Channel 2) for Style-7 operation.
Step Action Result
1 Press 0 Key Initiate menu access
2 Enter Password Gain access to menus
3 Press 3 Key Enter Set-Menu branch
4 Press "Scroll" Key Access additional options
5 Press 6 Key Select "Network" option
6 Press 1 Key Select “Style” option
7 Press one of the following:
1 Key
2 Key
3 Key
Selects Channel 1
Selects Channel 2
Selects both Channel 1 and 2
8 Press 2 Key Disable channel(s) selected in Step 7
9 Press "Enter" Key to confirm selection. Selected channel(s) disabled
10 Press "Backspace" Key (as required) Exit Menu System
11 Wait until "Initializing Configuration" message
disappears from the display.
Initialization complete
