3-2.5.2.5.14 How to Activate Remote Release Modules
Purpose: To manually activate one or more remote release modules
during system testing to confirm the proper operation.
Note: All remote release modules must be manually de-activated via
a menu operation or a system reset before the system can be
returned to normal operating condition.
CAUTION
There is no indication at the control unit that an output is activated. Be sure to
de-activate the output after proper operation has been confirmed.
Ensure that the control modules are not activating suppression systems or
controlling critical facility operations such as computer power. Physically
disconnect the wiring to all agent-release and pre-action-sprinkler circuits and
bypass all affected power-off circuits before activating any control modules if
the control modules are activating suppression systems or are shutting off
power. Restore the system to normal operating condition at the conclusion of
all control-module activations and any other functional tests.
Step Action Result
1 Press 0 Key Initiate Menu Access
2 Enter Password; press "Enter" Key Gain access to menus
3 Press 4 Key Enter Test-Menu branch
4 Press "Scroll" Key Access additional Test-Menu options
5 Press 7 Key Select "Output Test" option
6 Press "Scroll" Key twice Access additional Outputs-Test options
7 Press 8 Key Select "SLC Outputs"
8 Enter starting SLC address and ending SLC
address.
Use XXX format for addresses.
Press "Enter" Key to confirm address range of
control modules to de-activate.
Specify range of control modules to de-activate.
9 Press 2 Key and then press "Enter" Key Initiate control-module de-activation specified in
Step 8
10 Return to Step 8 and make another selection
(optional)
De-activate additional control modules
11 Press "Backspace" Key (as required) Exit Menu System
CAUTION
There is no indication at the control unit that an output is activated. Be sure to
de-activate the output after proper operation has been confirmed.
Ensure that the remote release modules are not activating suppression
systems. Physically disconnect the wiring to all agent-release and pre-action-
sprinkler circuits if the control modules are activating suppression systems.
Restore the system to normal operating condition at the conclusion of all RRM
activations and any other functional tests.
