ATMAddr Not Registered On The control unit has not been set up
to expect the ATM at ATM RS-485
circuit address Addr.
• Register the ATM if part of system
configuration. See
Paragraph 3-2.5.2.4.57. If this
procedure is insufficient, the
following procedure must also be
conducted:
• Upload a new application program
that includes the previously
unregistered ATM.
• De-register the ATM if not part of
system configuration. See
Paragraph 3-2.5.2.4.58.
• Check the 24 Vdc power (Terminal
Block TB3)and RS-485
communications wiring (Terminal
Blocks TB1 and TB2) from the
control unit to the ATM
• Ensure that the ATM Address
Switch S1 is set correctly.
• Refer to ATM Installation Manual,
P/N 06-236179-002.
ATMAddr PSU Fault On A loss of 24 Vdc power at Terminal
Block TB3 or an open circuit in the
monitoring circuit from the ATM's "PS
Flt" and "Com" terminals to the
normally-closed trouble contacts of
its associated remote power supply
• Refer to ATM Installation Manual,
P/N 06-236179-002.
• Check for 24 Vdc power at ATM
Ter mi nal Bl oc k TB3.
• Look for discontinuity in wiring to
remote-power-supply trouble
contacts. Jumper these terminals if
you are using the ARIES Control
Unit to power the ATM.
• Check for trouble with third-party
remote power supply
ATMAddr Reset Input Fault On An open circuit in wiring from the
ATM-L's "Reset" input terminal to the
associated annunciator's reset
switch. ATM-L address is Addr
• Refer to ATM Installation Manual,
P/N 06-236179-002.
• Look for discontinuity in wiring to
reset switch
• Check for missing 10k end-of-line
resistor.
ATMAddr Silence Input Fault On An open circuit in wiring from the
ATM-L's "Silence" input terminal to
the associated annunciator's alarm-
silence switch. ATM-L address is Addr
• Refer to ATM Installation Manual,
P/N 06-236179-002.
• Look for discontinuity in wiring to
alarm-silence switch
• Check for missing 10k end-of-line
resistor.
ATMAddr Silenced Output Fault On An open circuit in wiring from the
ATM-L's "Silence" output terminal to
the associated annunciator's alarm-
silence LED. ATM-L address is Addr
• Refer to ATM Installation Manual,
P/N 06-236179-002.
• Look for discontinuity in wiring to
alarm-silence LED (if used)
• Check for missing 20k supervising
resistor if alarm-silence LED not
used.
Table 5-5. Remote-Display/Annunciator Events (Continued)
Remote-Display/Annunciator
Events
Error Message Probable Cause Corrective Action
