Unmapped Network Node XX on CH.
Y On
Node XX is connected to and
communicating on the network via
Channel Y but is not registered
• Add node to network. Refer to
Section 3-2.5.2.4.44. This is not
sufficient by itself. See next step.
• Review network settings and
required interactions among
control units in the applications
program. Make any necessary
corrections and re-upload
configurations again to all effected
nodes.
• Check wiring to NIC in Node XX.
See Section 2-17. Ensure that
network wiring is daisy-chained
and not T-Tapped.
• Check network wiring for excess
resistance or capacitance.
• Check connection of NIC to main
printed circuit board Header J5.
See Figure 1-8 and Section 2-17.
WARNING
Do not leave a facility after performing any of the corrective actions listed in
this chapter until you have:
· Performed sufficient system testing to ensure that the problem(s) has
(have) been corrected and that the system is in proper working condition
· Physically re-connected the wiring to actuator assemblies (if used) to the
release-circuits from which they were removed
· Physically re-connected all control heads (if used) to the associated agent-
storage-container discharge valves from which they were removed
· Physically re-connected the wiring to solenoid valves (if used) for pre-
action/deluge sprinkler systems
· Ensured that emergency operations controlled by this system such as facility
power shutoff are restored
· Notified personnel in the facility and at off-premises monitoring locations
that you have finished working on the system, that system servicing has
ended, and that the system has been restored to proper working conditions.
Table 5-6. Network Events (Continued)
Network Events
Error Message Probable Cause Corrective Action
