Kioti DK6010 - Additional Weight (Option)

4
-
60 DK6010
(1) Additional Front Weight
If the loader is not installed, attach a
weight to the front frame of the trac-
tor as a safety measure.
If a heavy implement is installed at
the rear or when towing a heavy
trailer, the front wheels may be lifted.
Add sufcient weight to keep steer-
ability and to prevent rollover.
If sufficient weight, such as front
loader, is applied to the front wheels,
remove the extra front weight.
ADDITIONAL WEIGHT (OPTION)
ADDITIONAL FRONT WEIGHT
111
D21O434A
If the front tires are excessively load-
ed, it becomes hard to steer the trac-
tor, the tires can be worn faster and
the durability of the front axle can be
deteriorated.
When i nstalling or r emoving a
weight, always check the tire ination
pressure and adjust it as necessary.
The front weights are available at the
KIOTI Dealer. For required number
of weights, consult your local KIOTI
Dealer.
COMPONENTS FOR ADDITIONAL
FRONT WEIGHT (OPTION)
(1) Front Weight
(2) Pin
(3) Front weight Bolt
(4) Hex Head Screw
(5) Plate
(6) Bracket
(7) Spring Washer
(8) Plain Washer
(9) Clip pin
1
3
7
7
3
4
4
6
7
7
8
9
8
6
2
2
5
D21O443A
