Kioti DK6010 - Replacing BULB (Aq)

7
-
44
DK6010
The bulbs and their capacity used
in this tractor are listed in the below
table. This section only describes
procedures the users can handle.
REPLACING BULB (AQ)
Sequence Bulb Capacity
1 Headlamp 35W/35W
2 Position lamp (Front) 5W
3 Stop/Position lamp (Rear) 21W/5W
4 Turn signal lamp 21W
5 Work lamp 21W
6
Instrument
cluster
Indicator
Charging
warning
light
3W
Others 1.4W
7 Backup lamp 10W
HEADLAMP
1. Turn the key switch to the “OFF”
position and open the hood.
(1) Hood (2) Opening Knob
(A) Pull (B) Open
111
AA
BB
22
D21O701A
(1) Cap (2) Connector
2. Remove the cap.
3. Press and turn the socket coun-
terclockwise to remove the bulb. If
the bulb is blown, replace it with a
new bulb with the same capacity.
D21O714A
