ENGINE COOLANT TEMPERATURE GAUGE TURN SIGNAL LAMP
Operating the turn signal lamp switch
up and down turns on the corre-
sponding lamp in green.
Make sure to control the work
load so that the needle is not
in the red zone.
If the needle stays in the red
zone, do not stop the engine
immediately. Instead, reduce
the work load to cool down
the engine before stopping the
engine.
Make sure to keep the front
grill clean so that air is sucked
through it freely for fast cooling.
•
•
•
CAUTION
This gauge indicates the coolant
temperature after the key switch is
turned to the "ON" position.
•
C : Coolant is cold.
•
H : Coolant is hot.
The range marked in "H" in the gure
indicates the abnormal engine tem-
perature. Reduce the engine rpm im-
mediately.
(1) Coolant Temperature Gauge
C: Cold H: Hot
