7
-
30
DK6010
(1) Power Steering Oil Line
1. Check to see that all hydraulic
lines and hose ttings are tight and
undamaged.
2. If damage is found you should re-
place the hose or clamp at once.
td2O729A
POWER STEERING LINE (AA)
(1) Adjusting Screw (2) Lock Nut
ADJUSTING FRONT AXLE PIVOT
PIN (AD)
If the front axle pivot pin adjustment
is not correct, front wheel vibration
can occur.
ADJUSTING PROCEDURE
Loosen the lock nut, tighten the ad-
justing screw all the way, and then
loosen the screw by 1/6 turn. Re-
tighten the lock nut.
td2O730A
Improper adjustment of the valve clear-
ance can reduce the performance
and / or damage the engine. This ad-
justment should only be preformed by
a certied KIOTI dealer.
ADJUSTING ENGINE VALVE
CLEARANCE (AE)
