Kioti DK6010 - L Indicator (if EQUIPPED); PTO Indicator

4
-
22 DK6010
If the range shift is at low speed, this
lamp turned in green.
L INDICATOR (IF EQUIPPED)
-
TD2O414E
PTO INDICATOR
This indicator shows the PTO en-
gagement condition. When the PTO
is engaged, this indicator comes on.
When the PTO clutch is disengaged,
this indicator goes off.
When standing up from the seat with
the PTO on, the parking lamp will
illuminate, and the ignition will be
turned off 2 seconds after the buzzer
sounds.

Set t he P TO s w itc h t o t he
"OFF" position in order to start
the engine.
CAUTION
TD2O415E
