Kioti DK6010 - 4 WD Indicator (if EQUIPPED); H Indicator (if Equipped)

4
4
-
21FUNCTION DESCRIPTION AND OPERATING TIPS
4WD INDICATOR (IF EQUIPPED)
This comes on to indicate 4WD en-
gagement.
The 4WD indicator is turned off tem-
porarily while the quick turn mode is
in operation.
The durability of the axle can be
deteriorated if only one brake
pedal is depressed while the
4WD is activated.
•
CAUTION
If the range shift is at high speed,
this lamp turned in green.
H INDICATOR (IF EQUIPPED)
)
TD2O413E
For the safety reason, this is acti-
vated only when the range shift gear
is not in the low speed position.
Using the one-side brake on the cor-
responding side with the quick-turn
function can further reduce the turn-
ing radius.
TD2O411E
