Kioti DK6010 - Page 53

SPECIFICATIONS
3
3
-
3
A1
A2
D
F
C
E2
E1
B
※
These dimensions are measured with the standard
tires. (AG)
TD2O488A
※
A1: Overall length including weight
A2:
Overall length excluding weight
E1: Front wheel tread E2: Rear wheel tread
CABIN
mm (in.)
※
There may be differences in specications depending on the tire size.
ITEM
CABIN MODEL
DK6010C / DK6010CH
1. Overall length (A1) 3.320 (130,7)
2. Overall length (A2) 3.189 (125,5)
3. Overall width (B) 1.596 (62,8)
4. Overall height (C) 2.363 (93,0)
5. Wheel base (D) 1.810 (71,3)
6. Tread (E1) 1.252 (49,3)
7. Tread (E2) 1.251 (49,2)
8. Ground clearance (F) 368 (14,5)
