Kioti DK6010 - Page 56

DK6010
3
-
6
※
The specications are subject to change without notice.
ITEM
MODEL
DK6010H DK6010CH DK6010C DK6010N
PTO
Rear
Type Independent
PTO shaft SAE 1-3/8, 6 splines
Speed rpm
540 540 540/750 540/540E
Min. turning radius
(with one rear wheel braked)
mm (in.) 2.630 (103,5) 3.420 (134,6)
Weight kg (lbs.) 1.598 (3.523) 1.887 (4.160) 1.848 (4.074) 1.610 (3.549)
Draw-bar
(Clevis type)
Max. Drawbar vertical load daN (lbs.) 750 (1.650)
Max. Trailer loading weight
kg (lbs.) 4.300 (9.480)
※
N: Narrow type
