NOTE : Implement size may vary depending on soil operating conditions.
Item
Model
Actual gures
Trailer loading weight
W
3
Max. capacity
Implement weight W
1
and /
or size
Max. Drawbar Load W
2
ALL
As in the following list
(shown on the next page)
750 kg (1.650 lbs.) 4.300 kg (9.480 lbs.)
Lifting Capacity max. loading weight .............The max. allowable load which can be put on the 24 in. aft of hitch : W
0
Implement weight ..........................................The implement's weight which can be put on the lower link : W
1
Max. drawbar load .........................................W
2
Trailer loading weight ....................................The max. loading weight for trailer (without trailer's weight) : W
3
S42O301A
