KOB PYROT - Page 10

Trade name Pyrot rotation combustion
Rated output kW 100 150 220 300 400 540
Part no.: 7423 656 7423 657 7423 658 7423 659 7423 660 7423 661
Flue gas
*5
Average temperature (gross
*6
)
–
Average flue gas temperature with Q
N
*7
°C 160 160 160 160 160 160
– Average flue gas temperature with Q
min
°C 130 130 130 130 130 130
Mass flow rate
– Q
N
; W5; O
2
6 % g/s 53.6 80.4 117.9 160.8 214.4 289.44
– Q
W35
; W35; O
2
8 % g/s 71.3 106.9 156.9 213.9 285.2 385.1
Flow rate
– Q
N
; W5; O
2
6 %; 150 °C
m
3
/s
0.06 0.09 0.14 0.19 0.25 0.35
– Q
W35
; W35; O
2
8 %; 150 °C
m
3
/s
0.08 0.12 0.19 0.25 0.34 0.46
CO
2
content in the flue gas % 15 15 15 15 15 15
Flue outlet 7 mm 200 250 250 300 350 350
Required draught Pa 0 0 0 0 0 0
Efficiency
– At full load % 90 90 90 90 90 90
– At partial load % 92 92 92 92 92 92
*5
Values for calculating the size of the flue system to DIN EN 13384, based on 12.0 % CO
2
*6
Actual flue gas temperature as average gross value as per EN 304 at 20 °C combustion air temperature
*7
Flue gas temperature: Increase possible by removing the displacer rods (Q
N
+ 30 °C; Q
min
+ 10 °C)
PYROT rotation combustion
(cont.)
10
PYROT
2
5822 516 GB
