Subindex 2 contains four ASCII - characters, which determine the voltage range and current class of the device.
The voltage range is one character L, M or H for low, medium and high voltage. The next three characters are
showing the continuos current of the drive.
Subindex 2
Description Product Code
Category optional
Access R/O
PDO mapping not possible
Value range e.g. M006 for an MV6 drive
Default value no
Subindex 3 consists of two revision numbers:
l the major revision number in the upper word containing the CAN-version
l the minor revision number is not used in the AKD. The firmware version can be retrieved as a string via object
0x100A or as numbers voa object 0x2018 subindex 1 to 4.
E.g. a value of 0x0014 0000 means CAN-version 0.20.
Subindex 3
Description Revision Number
Category optional
Access R/O
PDO mapping not possible
Value range UNSIGNED32
Default value no
Subindex 4 gives the serial number of the drive. This number contains the following information in it:
l bits 0..14: Board serial number (production in week of year)
l bits 15..20: week of production
l bits 21..24: year of production - 2009
l bits 25..31: ASCII-code of MFR-ID
Subindex 4
Description Serial Number
Category optional
Access R/O
PDO mapping not possible
Value range UNSIGNED32
Default value no
AKD CANopen | 7 CANopen Drive Profile
Kollmorgen™ | November 2012 57
