7.2.1.14 Object 1014h: COB-ID for Emergency Message (DS301)
This object defines the COB-ID of the Emergency message.
Index 1014h
Name COB-ID emergency message
Object code VAR
Data type UNSIGNED32
Category conditional; mandatory, if Emergency is supported
Access R/O
PDO mapping not possible
Value range UNSIGNED32
Default value 80h + Node - ID
7.2.1.15 Object 1016h: Consumer Heartbeat Time
The consumer heartbeat time defines the expected heartbeat cycle time (ms) and must be higher than the cor-
responding producer heartbeat time configured on the device producing this heartbeat. Monitoring starts after the
reception of the first heartbeat. If the consumer heartbeat time is 0 ms the corresponding entry is not used.
Index 1016h
Name consumer heartbeat time
Object code ARRAY
Data type UNSIGNED32
Category optional
Subindex 0
Description number of entries
Data type UNSIGNED8
Category mandatory
Access R/O
PDO Mapping not possible
Value range 1
Default value 1
Subindex 1
Description Consumer heartbeat time
Category mandatory
Access R/W
PDO Mapping not possible
Value range unsigned 32
Default value no
Definition of the entry value of Subindex 1
MSB LSB
Value reserved (value: 00) Node-ID heartbeat time
Encoded as - UNSIGNED8 UNSIGNED16
Bit
31 24 23 16 15 0
AKD CANopen | 7 CANopen Drive Profile
Kollmorgen™ | November 2012 55
