AKD CANopen | 7 CANopen Drive Profile
7.2.3 Profile specific objects
7.2.3.1 Object 60B8h: Touch probe function
This object indicates the configured function of the touch probe.
Index 60B8h
Name Touch probe function
Object code Variable
Data type UNSIGNED16
Category optional
Access R/W
PDO Mapping yes
Value range UNSIGNED16
Default value 0
Definition of the possible functions:
Bit Value Meaning
0 0 Switch off touch probe 1
1 Enable touch probe 1
1 0 Trigger first event
1 Continuous
3, 2 00b Trigger with touch probe 1 input
01b Trigger with zero impulse signal or position encoder
10b Touch probe source as defined in object 60D0h, sub-index 01h
11b reserved
4 0 Switch off sampling at positive edge of touch probe 1
1 Enable sampling at positive edge of touch probe 1
5 0 Switch off sampling at negative edge of touch probe 1
1 Enable sampling at negative edge of touch probe 1
6, 7 - User-defined (e.g. for testing)
8 0 Switch off touch probe 2
1 Enable touch probe 2
9 0 Trigger first event
1 continuous
11, 10 00b Trigger with touch probe 2 input
01b Trigger with zero impulse signal or position encoder
10b Touch probe source as defined in object 60D0h, sub-index 02h
11b reserved
12 0 Switch off sampling at positive edge of touch probe 2
1 Enable sampling at positive edge of touch probe 2
13 0 Switch off sampling at negative edge of touch probe 2
1 Enable sampling at negative edge of touch probe 2
14, 15 - User-defined (e.g. for testing)
