Kollmorgen AKD User Manual

7.2.2.14 Object 3475h: Parameters for digital outputs
This set of objects is used to set extended parameters for some digital output functions. The parameters can be
used for different DOUTx.MODEs. Therefore the scaling might be different or no scaling is used at all.
Two subindices build an access object to one of these parameters, because they are 64-bit numbers internally,
e.g. object 3475 sub 1 gives access to the low 32 bits of DOUT1.PARAM whereas 3475 sub 3 gives access to
the high 32 bits.
If access to the whole 64 bit number is needed the higher bits must be written first. The access to the lower 32
bits then writes the parameter. If the to be written value fits into 32 bit, only the lower part needs to be written.
The most-significant bit is then taken as sign-bit for the number.
Index 3475h
Name DOUTx.PARAM
Object code Array
Data type UNSIGNED32
Category optional
Subindex 0
Description number of entries
Category mandatory
Access R/O
PDO mapping not possible
Value range 0x4
Default value 0x4
Subindex 1 to 2
Description DOUTx.PARAM low 32 bits, x = 1 .. 2
Category optional
Access R/W
PDO mapping not possible
Value range UNSIGNED32
Default value 0
Subindex 3 to 4
Description DOUTx.PARAM high 32 bits, x = 1 .. 2
Category optional
Access R/W
PDO mapping not possible
Value range UNSIGNED32
Default value 0
AKD CANopen | 7 CANopen Drive Profile
Kollmorgen™ | November 2012 69
