SECTION 3 - PARTS, ASSEMBLIES & HARDWARE

1-3-17

3-17

CONCERTO UPRIGHT

(Original Instructions)

P/n 310644 assy, Main deck and FraMe

ITEM PART # DESCRIPTION

1. 130969 ASSY, FRAME, DECK

2. 192731 GRILLE, SPEAKER (2)

3. 450428 SCREW, TPG, HEX WSHR HD, 8-32 X .250 (25)

ITEM PART # DESCRIPTION

4. 470077 SEAL, GRILLE, SPEAKER (2)

5. 610090 DECK, CAST, LWR, MAIN

6. 610091 DECK, CAST, UPR, MAIN
