SECTION 3 - PARTS, ASSEMBLIES & HARDWARE
1-3-2
3-2
© 2018 Konami Gaming Inc. P/N 810237
CONCERTO UPRIGHT
(Original Instructions)
coMMonly-used HardWare
The following table shows the hardware that this machine
uses. Using incorrect hardware may damage the equipment.
PART
NO.
DESCRIPTION
450013 NUT, HEX KEP #10-32
450014 NUT, HEX KEP #4-40
450015 NUT, HEX KEP #6-32
450016 NUT, HEX, KEP #8-32
450018 NUT, HEX, KEP M4
450107 SCREW, SEMS, PAN HEAD PHILLIPS, #4-40 X 1/4
450108 SCREW, SEMS, PAN HEAD PHILLIPS, #4-40 X 3/8
450109 SCREW, SEMS, PAN HEAD PHILLIPS, #6-32 X 1/2
450110 SCREW, SEMS, PAN HEAD PHILLIPS, #6-32 X 1/4
450114 NUT, HEX, KEP #4-40
450115 SCREW, SEMS, PAN HEAD PHILLIPS, #8-32 X 1/4
450122 SCREW, SEMS, PAN HEAD PHILLIPS, M3 X 6
450123 SCREW, SEMS, PAN HEAD PHILLIPS, M3 X 8
450127 SCREW, SEMS, PAN HEAD PHILLIPS, M46
450144 NUT, NYLOK, #2-56
450146 GUIDE, PCB, 6”
450160 SPRING, EXTENSION, .25 DIA X 1 LONG
450161 SCREW, CONNECTOR MOUNTING
450163 RIVET, POP, 1/8 DIA X 3/8 LONG
450167 SCREW, PAN HEAD PHILLIPS, M3 X 12
450176 WASHER, #8 FLAT
450185 STAY, DOOR, 10.5”
450282 NUT, HEX, NYLOCK, #8-32
450285 WASHER, FENDER, #10, OD 1 X 7/32, ID 3/64
450366 NUT, HEX, #2-56
450410 CABLE TIE, 4”
450420 SCREW, TPG, HEX WSHR HD, #4-40 X .250
450428 SCREW, TPG, HEX WSHR HD, #8-32 X .250
450430 SCREW, TPG, HEX WSHR HD, #8-32 X .375
450513 SPCR, NYLON, .38 OD X .17 ID X .25L
450546 BUMPER, THRU-HOLE, W/WASHER
450573 GAS SPRING
450575 WASHER, .75 OD X .32 ID X .07 THK
450576 SPRING
450577 STANDOFF, HEX, F-F, 8-32 X 7/8” LG
450581 LATCH, DRAW, SPRING TENSION
450587 RING, RTNG, EXT, E-STYLE, 1/2 SHAFT
450588 HINGE, CONCEALED, 90DEG. OPENING
450589 SCREW, TPG, HEX WSHR HD, #10-32 X .375
450590 SCREW, TRUSS, HD, PHIL, #8-32 X .375, BLACK OXIDE
450596 SPACER, #8, .375 OD X .281 LG, NYLON, OFF-WHITE
450597 PLUG, HOLE, .625 DIA X .016-.125 PNL THKNS, BLK
450598 STUD, 8-32 X 1.25 w/ SLOT
450601 DAMPER, .235 LG X 76 STROKE, W/END FTG
450603 SCREW, TPG, PH PHIL, #8-32 X 1/4
450604 MAGNET, ADHESIVE BACKED, .25DIA X .10 THK
CAUTION: PCB’s may contain a lithium battery.
Danger of explosion if the battery is incorrectly
replaced. Replace only with the same, o r
equivalent type recommended by the manufacturer.
WARNING: Power to the machine must be turned off prior
to cleaning the inside of the machine or removing any
mechanical or electrical assembly. Unplug the machine.
WARNING: Hazardous high voltage exists within the
cabinet even with machine power off and the power
cord unplugged! Use extreme caution when removing
electrical assemblies to avoid injury. Discharge body
static BEFORE touching PCBs to avoid damaging
electrostatic sensitive components. Only qualified
personnel should attempt servicing this machine.
CAUTION: Distributors, Operators, and Users are
not to modify the equipment for any other use. Konami
Gaming, Inc. cannot be held liable for damages or injuries
resulting from use or modification of this equipment.
Konami Gaming, Inc. cannot be held liable for damages or
injuries arising from improper or unsupervised installation,
modification, or use of equipment not manufactured or
approved by Konami Gaming, Inc. This equipment is
designed as a gaming device for amusement only, for sale
and use in jurisdictions permitting such devices.
