SECTION 7 - GLOSSARY & INDEX
1-7-1
7-1
© 2018 Konami Gaming Inc. P/N 810237
CONCERTO UPRIGHT
(Original Instructions)
SECTION 7
Glossary & Index
A
No entry
B
Backplane
PCB located in the back of the Logic Unit housing.
Bill Acceptor
The Bill Acceptor validates, either accepting or rejecting bills
or coupons in various denominations.
Bill/Ticket Entry
The plastic bezel that guides the bill from the front of the
machine into the Bill Validator.
Bill Stacker Door Lock
Lock on the door of the bill validator restricting access to the
stacked bills.
Bill Stacker Door Switch
Security switch activates when bill stacker door is opened.
Bill Stacker Switch
Security switch that activates when stacker is removed.
Bill Validator Module
Unit that accepts valid currency while rejecting invalid bills.
Part of the Bill Acceptor.
C
Candle
Light mounted on the top of the machine, used to display
errors, jackpots or other conditions.
Clock
Internal timing device used to track date, time and year of
events.
Control Panel Unit
Panel with play button.
Controller
The touch screen controller.
Counter PCB
PCB holding the EM meters.
Counter Unit
Assembly consisting of the counter PCB and the housing,
light and harness.
D
Dashboard
The dashboard displays the game status information,
attendant message, game instruction, Denomination sign,
and other meters.
DC Fan
12 VDC cooling fan.
Deck
The door that the game play buttons, player tracking panel,
and speakers are installed on.
Display
The location of the 27” LCDs.
Door Connector PCB
PCB located on the inside of the Main Door close to the
cabinet. It is the main hub for all door connections (buttons,
coin comparitor).
Door Lock Sensor
Sensor used to determine the position of the door lock cam
or door lock.
Drop Box Switch
Switch used to determine when the Drop Door has been
opened.
