SECTION 7 - GLOSSARY & INDEX
1-7-2
7-2
© 2018 Konami Gaming Inc. P/N 810237
CONCERTO UPRIGHT
(Original Instructions)
L
LED PCB
PCB to control LEDs.
Logic Door Lock
Lock used to secure the Logic Door.
Logic Door Switch
Switch used to monitor the Logic Door position (opened or
closed).
Logic Unit
Unit that houses the Main Processing Unit (MPU) printed
circuit board.
M
Machine Type
Series name of the cabinet.
Main Door
The front door of the machine providing access to the main
internal components.
Main Door Switch
The switch monitoring the position of the Main Door (opened
or closed).
Manufacture Date
Date the machine was manufactured.
MPU
Main Processing Unit printed circuit board.
N
No entry
O
Operation Buttons
Buttons used to navigate the menu systems.
F
Function Button
Buttons attached to the monitor mask on the left side of the
game (usually Cash Out, Pay Table and Help).
Function Button Panel
The assembly holding the function buttons.
G
Game Area
The game area displays image that corresponds to game
type.
Game Screen
Game Screen is composed of four areas, which are game
area, sub game area, sub message area and dashboard.
H
No entry
I
No entry
J
Jumper Sockets
Sockets on a PCB allowing multiple settings by changing the
conguration of shorting connector.
K
Key Switch
An electro-mechanical switch activated by using a key.
