20-16
Effects
Pitch/Phase Mod.
024: RandomPhser
(Stereo Random Phaser)
This is a stereo phaser. The effect uses a step-shape waveform
and random LFO for modulation, creating a unique phasing
effect.
025: Envel.Phser
(Stereo Envelope Phaser)
This stereo phaser uses an envelope generator for modula-
tion. You will obtain the same pattern of phasing each time
you play. You can also control the Phaser directly using the
modulation source.
a
LFO Waveform Step-Tri, Step-Sin, Random
Selects LFO Waveform
Fx:010
b
LFO Phase [degree] –180...+180
Sets the LFO phase difference between the left and right
Fx:010
c
LFO Frequency [Hz] 0.02...20.00Hz
Sets the LFO speed
Fx:010,
Src Off...Tempo
Selects the modulation source commonly used for LFO speed and step
speed
Amt –20.00...+20.00Hz
Sets the modulation amount of LFO speed
d
LFO Step Freq (Frequency) [Hz] 0.05...50.00Hz
Sets the LFO step speed
Fx:010,
Amt –50.00...+50.00Hz
Sets the modulation amount of LFO step speed
e
BPM/MIDI Sync Off, On
Switches between using the frequency of the LFO speed and using the
tempo and notes
Fx:009,
BPM
Selects MIDI Clock and assigns tempo
MIDI, 40...240
009, 010
Base Note
                 
Selects the type of notes that specify the LFO speed Fx:009
Times x1...x16
Sets the number of notes that specify the LFO speed
Fx:009
f
Step Base Note
                      
Selects the type of notes to specify the LFO step speed
Fx:010,
Times x1...x32
Sets the number of notes to specify the LFO step speed
Fx:010
g
Manual
Sets the frequency to which the effect is applied
0...100
h
Depth
Sets the depth of LFO modulation
0...100
i
Resonance
Sets the resonance amount
–100...+100
Fx:023
High Damp [%] 0...100%
Sets the resonance damping amount in the high range
Fx:023
j
Wet/Dry –Wet...–1:99, Dry, 1:99...Wet
Table , “Sets the balance between the effect and dry sounds,” on page 1
Fx:010, 023,
Src Off...Tempo
Table , “Selects the modulation source of the effect balance,” on page 1
Amt
Table , “Sets the modulation amount of the effect bal-
ance,” on page 1
–100...+100
LFO: Step-Tri/Random
Left
Right
Resonance
LFO Phase
Wet / Dry
Wet / Dry
High Damp
Stereo In - Stereo Out
Phaser
Phaser
a
L Manu Bottom (L Manual Bottom) 0...100
Sets the lower limit of the frequency range for the effect on the left channel
Fx:009
L Manu Top (L Manual Top) 0...100
Sets the upper limit of the frequency range for the effect on the left channel
Fx:009
b
R Manu Bottom (R Manual Bottom) 0...100
Sets the lower limit of the frequency range for the effect on the right channel
Fx:009
R Manu Top (R Manual Top) 0...100
Sets the upper limit of the frequency range for the effect on the right chan-
nel
Fx:009
c
Sweep Mode EG, D-mod
Determines whether the flanger is controlled by the envelope generator or
by the modulation source
Fx:022,
Src Off...Tempo
Selects the modulation source that triggers the EG (when EG is selected for
Sweep Mode), or modulation source that causes the flanger to sweep
(when D-mod is selected for Sweep Mode)
d
EG Attack
Sets the EG attack speed
1...100
Fx:022
EG Decay
Sets the EG decay speed
1...100
Fx:022
e
Resonance
Sets the resonance amount
–100...+100
Fx:023
f
High Damp [%] 0...100%
Sets the resonance damping amount in the high range
Fx:023
g
Wet/Dry –Wet...–1:99, Dry, 1:99...Wet
Table , “Sets the balance between the effect and dry sounds,” on page 1
Fx:010, 023,
Src Off...Tempo
Table , “Selects the modulation source of the effect balance,” on page 1
Amt
Table , “Sets the modulation amount of the effect bal-
ance,” on page 1
–100...+100
EG Attack/Decay
EG
D-mod
Sweep Mode
D
-mod
Phaser
Phaser
Left
Right
Resonance
Wet / Dry
Wet / Dry
High Damp
Stereo In - Stereo Out
