Kyocera Ecosys P2235dn Service Manual

2RV/2RW/2RX/2RY/3RA
5-3
(The first page)
The first line: "FW-Update"
Page number/total page number and upper and
lower key icon are displayed.
The second line: "Completed" (Completion message)
(The second and subsequent page)
The first line: "CTRL", (the character string applicable to the
update target)
Page number/total page number and upper and lower
key icon are displayed.
The second line: (updated version)
*: When there is no applicable master file, "No Change" is dis-
played.
*: "*" is displayed after the update target name when it has been
skipped.
7. Check if the new firmware versions are displayed.
8. Unplug the power cord and disconnect the USB memory.
9. Connect the power cord and turn the power switch off after checking that "Ready to copy" is displayed.
In case of any error (the error which can not read a file), the process is interrupted immediately and the com-
pletion is displayed without executing the subsequent firmware update.
(The first page)
The first line: "FW-Update"
Page number/total page number and upper and lower
key icon are displayed.
The second line: "Error"
(The second and subsequent page)
The first line: "ENGN", (the character string applicable to the
update target)
Display page number/total page number, upper and
lower key icon
The second line: "Error", error code
Error code
Code Error contents Code Error contents
0000 Others S000 Other signature verification error
0100 There is no master file. S001 The signature verification file is insuffi-
cient.
0200 Master file version discrepancy N001 Unable to connect the network *2
(There is no target to update.)
03xx *4 There is no download file (No.xx).
04xx *4 File (No.xx) check sum discrepancy N002 Can not connect to the network *3
(There is the target to update.)
05xx *4 File (No.xx) preparation failure
FW-Update 1/10
Completed
[CTRL] 2/10
2RB_2000.001.005
[ENGN] 9/10
No Change
[CTRL] 2/10
2S1_2000.001.005
FW-Update 1/10
Error
[ENGN] 10/10
Error 0100

Kyocera Ecosys P2235dn Specifications

General

Style	Desktop
Color	White
Control Panel	LED Display
Noise Level	-
Interface Connectors	USB Host x 1
Wireless Connectivity	Wireless LAN/WiFi Direct
Apple Macintosh OS X 10.5 or later; Linux	Mac OS X 10.6.8
Mac OS® X 10.6.8 – 10.10.x8	Windows XP
10.6 - 10.10	Windows XP
MPT: Min. A6R - Max. A4R (Legal)	13 x 18 cm
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	Cassette: Min. A6R – Max. A4 (Legal)
MPT: Min. A6R – Max. A4 (Legal)	4 in x 6 in
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	B5
Manual Feed Slot: Letter	Executive
Functions	-
Features	Wireless
Printing Method	Semiconductor Laser
Nozzles	-
First Page Print Time	6.8 Seconds or Less
Warm Up Time	15 Seconds or Less (Power On)
Print Resolution	600 x 600 dpi
Scanner Type	-
300 DPI 9	-
Scan Resolution	-
Scan Formats	Max scan size 8.5 x 14.0"" (21.6 x 35.6 cm)
Copy Modes	text and image
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	4 Watt (sleep mode)
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	15.5 in
Height	10.7 in
Width	14.8 in
Net Weight	11.9 lbs
