Kyocera Ecosys P2235dn Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-71
C0150: Engine EEPROM data error
1. After writing in the EEPROM, written value and readout value after writing mismatched 8 times consecu-
tively.
2. After reading from the EEPROM, readout value from the same location mismatched 8 times consecutively.
C0160: Engine EEPROM data error
The data read from the EEPROM is judged as abnormal.
C0170: Charger count error
The values in one of the billing counters, life counter or the scanner counter mismatch between the main side
and the engine side.
Step Check description Assumed cause Measures Reference
1 Resetting the main power The EEPROM does not
operate properly.
Turn off the power switch and
unplug the power cord. After
5s passes, reconnect the
power cord and turn on the
power switch.
2 Reinstalling the EEPROM The EEPROM is not prop-
erly attached.
Reattach the EEPROM on
the main/engine PWB.
3 Replacing the EEPROM The EEPROM is faulty. Replace the EEPROM on the
main/engine PWB and exe-
cute U004.
4 Checking the main/engine
PWB
The connector is not con-
nected properly or the wire
or main/engine PWB is
faulty.
Reconnect the connector of
the main/engine PWB. If the
wire is pinched or scratched,
repair or replace it. If not
repaired, replace the main/
engine PWB.
Step Check description Assumed cause Measures Reference
1 Resetting the main power The EEPROM does not
operate properly.
Turn off the power switch and
unplug the power cord. After
5s passes, reconnect the
power cord and turn on the
power switch.
2 Executing U021 The data saved in the
EEPROM is faulty.
Execute U021.
3 Replacing the EEPROM The EEPROM is faulty. Replace the EEPROM on the
main/engine PWB and exe-
cute U004.
Step Check description Assumed cause Measures Reference
1 Checking the machine
serial number in the
EEPROM on the main/
engine PWB
The main/engine PWB for
the different main unit is
installed.
Check the main and engine
machine serial number in
U004 and if the main number
is different, attach the correct
main/engine PWB.

Kyocera Ecosys P2235dn Specifications

General

Style	Desktop
Color	White
Control Panel	LED Display
Noise Level	-
Interface Connectors	USB Host x 1
Wireless Connectivity	Wireless LAN/WiFi Direct
Apple Macintosh OS X 10.5 or later; Linux	Mac OS X 10.6.8
Mac OS® X 10.6.8 – 10.10.x8	Windows XP
10.6 - 10.10	Windows XP
MPT: Min. A6R - Max. A4R (Legal)	13 x 18 cm
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	Cassette: Min. A6R – Max. A4 (Legal)
MPT: Min. A6R – Max. A4 (Legal)	4 in x 6 in
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	B5
Manual Feed Slot: Letter	Executive
Functions	-
Features	Wireless
Printing Method	Semiconductor Laser
Nozzles	-
First Page Print Time	6.8 Seconds or Less
Warm Up Time	15 Seconds or Less (Power On)
Print Resolution	600 x 600 dpi
Scanner Type	-
300 DPI 9	-
Scan Resolution	-
Scan Formats	Max scan size 8.5 x 14.0"" (21.6 x 35.6 cm)
Copy Modes	text and image
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	4 Watt (sleep mode)
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	15.5 in
Height	10.7 in
Width	14.8 in
Net Weight	11.9 lbs
