Kyocera Ecosys P2235dn Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-72
C0180: Machine serial number mismatch
Machine serial number mismatch between the main and engine side when turning the power on.
2 Checking the machine
serial number in the
EEPROM on the main/
engine PWB
The EEPROM for the dif-
ferent main unit is
installed.
Check the main and engine
machine serial number in
U004 and if the engine num-
ber is different, install the cor-
rect EEPROM in the main/
engine PWB.
3 Replacing the main/engine
PWB
The main/engine PWB is
faulty.
Check the main and engine
machine serial number in
U004 and if the main number
is different, replace the main/
engine PWB and execute
U004.
4 Checking the EEPROM The EEPROM is faulty. Check the main and engine
machine serial number in
U004 and if the engine num-
ber is different, reinstall the
EEPROM in the main/engine
PWB. If not repaired, replace
the EEPROM and execute
U004.
Note: Do not execute U004
(selecting [Execute] and
pressing the [Start] key). A
different machine serial num-
ber is overwritten.
4 Replacing the main/engine
PWB
The main/engine PWB is
faulty.
Replace the main/engine
PWB.
Step Check description Assumed cause Measures Reference
1 Checking the machine
serial number in the
EEPROM on the main/
engine PWB
The main/engine PWB for
the different main unit is
installed.
Check the main and engine
machine serial number in
U004 and if the main number
is different, attach the correct
main/engine PWB.
2 Checking the machine
serial number in the
EEPROM on the main/
engine PWB
The EEPROM for the dif-
ferent main unit is
installed.
Check the main and engine
machine serial number in
U004 and if the engine num-
ber is different, install the cor-
rect EEPROM in the main/
engine PWB.
3 Replacing the main/engine
PWB
The main/engine PWB is
faulty.
Check the main and engine
machine serial number in
U004 and if the main number
is different, replace the main/
engine PWB and execute
U004.
Step Check description Assumed cause Measures Reference

Kyocera Ecosys P2235dn Specifications

General

Style	Desktop
Color	White
Control Panel	LED Display
Noise Level	-
Interface Connectors	USB Host x 1
Wireless Connectivity	Wireless LAN/WiFi Direct
Apple Macintosh OS X 10.5 or later; Linux	Mac OS X 10.6.8
Mac OS® X 10.6.8 – 10.10.x8	Windows XP
10.6 - 10.10	Windows XP
MPT: Min. A6R - Max. A4R (Legal)	13 x 18 cm
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	Cassette: Min. A6R – Max. A4 (Legal)
MPT: Min. A6R – Max. A4 (Legal)	4 in x 6 in
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	B5
Manual Feed Slot: Letter	Executive
Functions	-
Features	Wireless
Printing Method	Semiconductor Laser
Nozzles	-
First Page Print Time	6.8 Seconds or Less
Warm Up Time	15 Seconds or Less (Power On)
Print Resolution	600 x 600 dpi
Scanner Type	-
300 DPI 9	-
Scan Resolution	-
Scan Formats	Max scan size 8.5 x 14.0"" (21.6 x 35.6 cm)
Copy Modes	text and image
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	4 Watt (sleep mode)
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	15.5 in
Height	10.7 in
Width	14.8 in
Net Weight	11.9 lbs
