Kyocera Ecosys P2235dn Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-73
C0190: Backup memory device error (Engine)
The data is not read from the EEPROM when turning the power on. (3 retries)
C0500: Drive lock detection by the engine firmware
The main motor continuously rotates.
4 Checking the EEPROM The EEPROM is faulty. Check the main and engine
machine serial number in
U004 and if the engine num-
ber is different, reinstall the
EEPROM in the main/engine
PWB. If not repaired, replace
the EEPROM and execute
U004.
Note: Do not execute U004
(selecting [Execute] and
pressing the [Start] key). A
different machine serial num-
ber is overwritten.
5 Replacing the main/engine
PWB
The main/engine PWB is
faulty.
Replace the main/engine
PWB.
Step Check description Assumed cause Measures Reference
1 Resetting the main power The EEPROM is not prop-
erly read.
Turn off the power switch and
unplug the power cord. After
5s passes, reconnect the
power cord and turn on the
power switch.
2 Checking the main/engine
PWB
The connector is not con-
nected properly or the wire
or main/engine PWB is
faulty.
Reconnect the connector of
the main/engine PWB. If the
wire is pinched or scratched,
repair or replace it. If not
repaired, replace the main/
engine PWB.
3 Replacing the EEPROM The data is not properly
read since the EEPROM is
faulty.
Contact the service support
to acquire the new EEPROM,
and install it on the main/
engine PWB.
Step Check description Assumed cause Measures Reference
1 Resetting the main power The main/engine PWB
does not correctly operate.
Turn off the power switch and
unplug the power cord. After
5s passes, reconnect the
power cord and turn on the
power switch.
Step Check description Assumed cause Measures Reference

Kyocera Ecosys P2235dn Specifications

General

Style	Desktop
Color	White
Control Panel	LED Display
Noise Level	-
Interface Connectors	USB Host x 1
Wireless Connectivity	Wireless LAN/WiFi Direct
Apple Macintosh OS X 10.5 or later; Linux	Mac OS X 10.6.8
Mac OS® X 10.6.8 – 10.10.x8	Windows XP
10.6 - 10.10	Windows XP
MPT: Min. A6R - Max. A4R (Legal)	13 x 18 cm
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	Cassette: Min. A6R – Max. A4 (Legal)
MPT: Min. A6R – Max. A4 (Legal)	4 in x 6 in
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	B5
Manual Feed Slot: Letter	Executive
Functions	-
Features	Wireless
Printing Method	Semiconductor Laser
Nozzles	-
First Page Print Time	6.8 Seconds or Less
Warm Up Time	15 Seconds or Less (Power On)
Print Resolution	600 x 600 dpi
Scanner Type	-
300 DPI 9	-
Scan Resolution	-
Scan Formats	Max scan size 8.5 x 14.0"" (21.6 x 35.6 cm)
Copy Modes	text and image
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	4 Watt (sleep mode)
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	15.5 in
Height	10.7 in
Width	14.8 in
Net Weight	11.9 lbs
