Kyocera Ecosys P2235dn Service Manual

2RV/2RW/2RX/2RY/3RA
8-2
Connector access point
YC1: In-machine temperature sensor, Fuser pressure release motor, In-machine fan motor, Eject solenoid
YC2: Temperature humidity sensor, Waste toner sensor, Thermopile
YC3: Polygon motor
YC5: Eraser
YC6: MP paper sensor, Paper sensor, Container relay PWB
YC7: Eject fan motor
YC8: Inter lock switch
YC9: Main motor
YC10: Developer clutch, Feed clutch, Registration clutch
YC14: Toner sensor
YC16: Registration sensor, High voltage PWB
YC17: PF-1100
YC19: Fuser pressure release sensor, Rotation detection sensor, Eject sensor, Fuser terminal thermistor
YC20: Low voltage power supply PWB
YC21: MP solenoid
YC23: Power switch
YC501: USB
YC502: EtherNet
YC503: SD
YC504: Wi-Fi
YC505: APC PWB
YC507: Operation panel PWB(LCD model only)
YC507: Operation panel PWB(TSI model only)
YC510: USB PWB
YS1: EEPROM
Connec-
tor
Pin Signal I/O Voltage Description
YC1 1 +24V6FA - 24 V DC 24 V DC power source
2 EXISOLRE I 0/24 V DC Eject solenoid drive
3 PREMOTRE- I/O 0/24 V DC Pressure release motor drive
4 PREMOTRE+ I/O 0/24 V DC Pressure release motor drive
5 FAN1MOTRE I 0/24 V DC/
about12V
Left side fan drive
6 +24V6FA(FAN) - 24 V DC 24 V DC power (When fan stops, the out-
put is turned off)
7 GND - 0 V DC Ground
8 INTTMP I Analog In-machine temperature sensor output
YC2 1 HUMCLK O 0/3.3 V DC(pulse) Outside machine humidity sensor clock
2 HUMDATA_ I 0/3.3 V DC(pulse) Outside machine humidity sensor clock
signal
3 TMPDATA I Analog Outside temperature sensor clock signal
4 GND - 0 V DC Ground
5 FUSTMPSE1O I Analog Thermopile output 0
6 GND - 0 V DC Ground
7 +3.3V4LS - 3.3 V DC 3.3 V DC power supply
8 FUSTMPSE1A I Analog Thermopile output A

Kyocera Ecosys P2235dn Specifications

General

Style	Desktop
Color	White
Control Panel	LED Display
Noise Level	-
Interface Connectors	USB Host x 1
Wireless Connectivity	Wireless LAN/WiFi Direct
Apple Macintosh OS X 10.5 or later; Linux	Mac OS X 10.6.8
Mac OS® X 10.6.8 – 10.10.x8	Windows XP
10.6 - 10.10	Windows XP
MPT: Min. A6R - Max. A4R (Legal)	13 x 18 cm
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	Cassette: Min. A6R – Max. A4 (Legal)
MPT: Min. A6R – Max. A4 (Legal)	4 in x 6 in
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	B5
Manual Feed Slot: Letter	Executive
Functions	-
Features	Wireless
Printing Method	Semiconductor Laser
Nozzles	-
First Page Print Time	6.8 Seconds or Less
Warm Up Time	15 Seconds or Less (Power On)
Print Resolution	600 x 600 dpi
Scanner Type	-
300 DPI 9	-
Scan Resolution	-
Scan Formats	Max scan size 8.5 x 14.0"" (21.6 x 35.6 cm)
Copy Modes	text and image
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	4 Watt (sleep mode)
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	15.5 in
Height	10.7 in
Width	14.8 in
Net Weight	11.9 lbs
