Kyocera Ecosys P2235dn Service Manual

2RV/2RW/2RX/2RY/3RA
8-3
YC2 9 TPSDA I/O 0/3.3 V DC(pulse) Thermopile I2C communication data
10 TPSCL O 0/3.3 V DC(pulse) Thermopile I2C communication clock
11 GND - 0 V DC Ground
12 WTOFULSE I 0/3.3 V DC Toner full detection signal
13 +3.3V4LS - 3.3 V DC 3.3 V DC power supply
YC3 1 +24V6FA - 24 V DC 24 V DC power source
2 GND - 0 V DC Ground
3 PMOTREN O 0/5 V DC Polygon motor drive signal
4 PMOTRDYN I 0/3.3 V DC Polygon motor rotation stability signal
5 PMOTCLKN O 0/5 V DC(pulse) Polygon motor clock
YC5 1 GND - 0 V DC Ground
2 +24V6ILFERA - 24 V DC 24 V DC power (When the eraser is off,
the output is turned off.)
YC6 1 +3.3V2LED - about1.2 V DC Power for PI
2 GND - 0 V DC Ground
3 CASPAPSE I 0/3.3 V DC Cassette paper detection
4 +3.3V2LED - about1.2 V DC Power for PI
5 GND - 0 V DC Ground
6 MPFPAPSE I 0/3.3 V DC MPF paper detection
7 GND - 0 V DC Ground
8 CMDATA I/O 0/3.3 V DC Container communication
9-
YC7 1 +24V6FA - 24 V DC 24 V DC power source
2 FAN2MOTRE I 0/24 V DC Right side fan drive
YC8 1 +24V0IL - 24 V DC 24 V DC power (When the cover is
opened, the output is turned off.)
2 +24V0 - 24 V DC 24 V DC power source
YC9 1 MAIMOTDIR O 0/5 V DC Main motor rotaion's direction control sig-
nal
2 MAIMOTRDYN I 0/3.3 V DC Main motor rotation stability signal
3 MAIMOTCLKN O 0/5 V DC(pulse) Main motor clock
4 MAIMOTREN O 0/5 V DC Main motor drive signal
5 GND - 0 V DC Ground
6 +24V6IL - 24 V DC 24 V DC power (When the cover is
opened, the output is turned off.)
YC10 1 +24V6FA - 24 V DC 24 V DC power source
2 REGCLURE I 0/24 V DC Registration clutch drive
3 +24V6FA - 24 V DC 24 V DC power source
4 FEEDCLURE I 0/24 V DC Paper feed clutch drive
Connec-
tor
Pin Signal I/O Voltage Description

Kyocera Ecosys P2235dn Specifications

General

Style	Desktop
Color	White
Control Panel	LED Display
Noise Level	-
Interface Connectors	USB Host x 1
Wireless Connectivity	Wireless LAN/WiFi Direct
Apple Macintosh OS X 10.5 or later; Linux	Mac OS X 10.6.8
Mac OS® X 10.6.8 – 10.10.x8	Windows XP
10.6 - 10.10	Windows XP
MPT: Min. A6R - Max. A4R (Legal)	13 x 18 cm
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	Cassette: Min. A6R – Max. A4 (Legal)
MPT: Min. A6R – Max. A4 (Legal)	4 in x 6 in
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	B5
Manual Feed Slot: Letter	Executive
Functions	-
Features	Wireless
Printing Method	Semiconductor Laser
Nozzles	-
First Page Print Time	6.8 Seconds or Less
Warm Up Time	15 Seconds or Less (Power On)
Print Resolution	600 x 600 dpi
Scanner Type	-
300 DPI 9	-
Scan Resolution	-
Scan Formats	Max scan size 8.5 x 14.0"" (21.6 x 35.6 cm)
Copy Modes	text and image
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	4 Watt (sleep mode)
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	15.5 in
Height	10.7 in
Width	14.8 in
Net Weight	11.9 lbs
