Kyocera Ecosys P2235dn Service Manual

2RV/2RW/2RX/2RY/3RA
8-4
YC10 5 +24V6FA - 24 V DC 24 V DC power source
6 DLPCLURE I 0/24 V DC Developer clutch drive
7-
YC14 1 +3.3V4LS - 3.3 V DC 3.3 V DC power supply
2 ITOEMPSE I 0/3.3 V DC Toner empty detection signal
3 GND - 0 V DC Ground
YC16 1 PGND - 0 V DC Ground
2 SGND - 0 V DC Ground
3 +3.3V4LS - 3.3 V DC 3.3 V DC power supply
4 REGPAPSE I 0/3.3 V DC Registration sensor output
5 MHVCNT O 0/5 V DC(pulse) High voltage(M) output 310uA/155uA
switch
6 HVCLK O 0/5 V DC(pulse) High voltage(D) output pulse
7 RTHVREM O 0/5 V DC High voltage(M,T) output off/on
8 GHVCNT O 0/5 V DC(pulse) High voltage (M) output constant voltage/
constant current switch, G terminal volt-
age adjustment
9 DHVCNT O 0/5 V DC(pulse) High voltage (D) output DC voltage
adjustment
10 THVCNT O 0/5 V DC(pulse) High voltage (T) output constant current
off/on (output adjustment)
11 +24V6ILF - 24 V DC 24 V DC power (When the cover is
opened, the output is turned off.)
12 SHVCNT O Analog High voltage (S) output off/on (output
adjustment) : Japanese specification only
YC17 1 GND - 0 V DC Ground
2 +3.3V4LSF - 3.3 V DC 3.3 V DC power supply
3 +3.3V2 - 3.3 V DC 3.3 V DC power supply
4 PFINT I 0/3.3 V DC PF recovery factor detection
5 PFRDY I 0/3.3 V DC PF ready signal
6 PFSEL0 O 0/3.3 V DC PF select 1 signal
7 PFSEL1 O 0/3.3 V DC PF select 2 signal
8 PFCLK O 0/3.3 V DC(pulse) PF clock
9 PFTXD O 0/3.3 V DC(pulse) PF data sending signal
10 PFRXD I 0/3.3 V DC(pulse) PF data receiving signal
11 +24V6FB - 24 V DC 24 V DC power source
12 +24V6FB - 24 V DC 24 V DC power source
13 GND - 0 V DC Ground
Connec-
tor
Pin Signal I/O Voltage Description

Kyocera Ecosys P2235dn Specifications

General

Style	Desktop
Color	White
Control Panel	LED Display
Noise Level	-
Interface Connectors	USB Host x 1
Wireless Connectivity	Wireless LAN/WiFi Direct
Apple Macintosh OS X 10.5 or later; Linux	Mac OS X 10.6.8
Mac OS® X 10.6.8 – 10.10.x8	Windows XP
10.6 - 10.10	Windows XP
MPT: Min. A6R - Max. A4R (Legal)	13 x 18 cm
PC-Free Support: Plain: 8.5 x 11.0"" (21.6 x 27.9 cm)	Cassette: Min. A6R – Max. A4 (Legal)
MPT: Min. A6R – Max. A4 (Legal)	4 in x 6 in
Duplex Printing: A4 / Letter / Oficio / Folio / Legal / JIS B5 / ISO B5 / Executive / Statement	B5
Manual Feed Slot: Letter	Executive
Functions	-
Features	Wireless
Printing Method	Semiconductor Laser
Nozzles	-
First Page Print Time	6.8 Seconds or Less
Warm Up Time	15 Seconds or Less (Power On)
Print Resolution	600 x 600 dpi
Scanner Type	-
300 DPI 9	-
Scan Resolution	-
Scan Formats	Max scan size 8.5 x 14.0"" (21.6 x 35.6 cm)
Copy Modes	text and image
Max Copies	-
Copy Size	-
Copy Scale	-
Power Consumption	4 Watt (sleep mode)
Battery Life	-
Battery Capacity	-

Weight and Dimensions

Depth	15.5 in
Height	10.7 in
Width	14.8 in
Net Weight	11.9 lbs
