Kyocera FS-2020D - Duplex Conveying Section

2J0/2J1/2J2
2-1-14
2-1-9 Duplex conveying section
(1) Duplex conveying section
Figure 2-1-21Duplex conveying section
Figure 2-1-22Duplex conveying section block diagram










(1) DU roller
(2) DU feed pulley
(3) DU base
(4) DU lower guide
(5) Duplex jam sensor (actuator)
(6) Feed upper guide
Engine PWB
Duplex
clutch*
*: 40/42 and 45/47 ppm printers (EUR/USA model) only.
Connect-R PWB
Duplex jam
sensor
YC502-2
DUDRN
