Kyocera FS-2020D - 1-5-2 Outer Covers

2J0/2J1/2J2
1-5-3
1-5-2 Outer covers
(1) Detaching and refitting the top cover
Procedure
1. Open the top cover.
2. Remove two screws.
3. Remove the one connector and then
remove the top cover.
Figure 1-5-3
Connector
Screw
Screw
Top cover
