Kyocera FS-2020D Service Manual

2J0/2J1/2J2
1-3-9
Automatic drum surface refreshing
Description
The drum surface refreshing operation is normally performed when the power is turned on to
the printer or during warm-up when the printer is recovering from the Sleep mode, but even
then only at those times that the temperature/humidity sensor detects the drum surface to be
in a state of dew condensation. By using this mode, it is possible to force the drum surface
refreshing operation to be performed automatically at a predetermined period of time,
regardless of the status detected by the temperature/humidity sensor.
Purpose
To prevent bleeding of the output image when the printer's operating environment is one of
high humidity.
Method
1. Enter the maintenance mode [>>DRUM-CTRL].
2. Press the OK key. [>>DRUM-CTRL?] will be displayed.
3. Press the OK key.
4. Press the T key or S key and select the desire mode (from 00 to 02).
5. Press the OK key. The new value is set.
Completion
Drum surface refreshing
Description
Rotates the drum approximately 3 minutes with toner lightly on the overall drum using the
high-voltage output control of the engine PWB. The cleaning blade in the drum unit scrapes
toner off the drum surface to clean it.
Purpose
To clean the drum surface when image failure occurs due to the drum. This mode is effective
when dew condensation on the drum occurs.
Method
1. Enter the maintenance mode [>>Drum].
2. Press the OK key. [>>Drum?] will be displayed.
3. Press the OK key. Drum surface refreshing will start and finish after approximately 3 min-
utes, after which the printer reverts to the [Ready] state. [Ready] will displayed. Drum sur-
face refreshing is finished.
Completion
Maintenance items Description
>>DRUM-CTRL
00 Mode turned OFF (default)
01 Refreshing operation time (short)
02 Refreshing operation time (long)
>>Drum

Kyocera FS-2020D Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Memory type	DDR2
Processor model	PowerPC 440
Maximum internal memory	1152 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	52 dB
Power supply type	220/240 V, 50/60 Hz
Capacity cartridge	12000 sheets
Power consumption (active)	560 W
Recommended monthly print volume	20000 pages
Maximum duty cycle	150.000 pages per month
Number of print cartridges	1
Total input capacity	500 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	9.2 W
Power consumption (PowerSave)	5.7 W
Energy Star Typical Electricity Consumption (TEC)	2.6 kWh/week
Display	LCD
Certification	GS, TüV, CE
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	382 x 394 x 285 mm
