Kyocera FS-2020D - Detaching and Refitting the Fuser Heater Lamp

2J0/2J1/2J2
1-5-17
(2) Detaching and refitting the fuser heater lamp
Procedure
1. Remove the fuser unit (See page 1-5-16).
2. Open the exit upper guide.
3. Remove four screws.
Figure 1-5-21
ScrewScrew
Exit upper guide
Screw
Screw
