Kyocera FS-2020D - Detaching and Refitting the Press Roller

2J0/2J1/2J2
1-5-21
(4) Detaching and refitting the press roller
Procedure
1. Remove the fuser unit (See page 1-5-16).
2. Open the fuser upper frame (See page 1-5-
17).
3. Remove the press roller from the fuser lower
frame.
4. Check or replace the press roller and refit all
the removed parts.
Figure 1-5-26
Fuser lower frame
Press roller
