Kyocera FS-2020D Service Manual

2J0/2J1/2J2
1-4-1
1-4 Troubleshoo ting
1-4-1 Paper misfeed detection
(1) Paper misfeed indication
When a paper misfeed occurs, the printer immediately stops printing and displays the paper misfeed message on the
operation panel. To remove paper misfed in the printer, pull out the paper cassette, pull out the rear unit, remove the devel-
oping unit or open the duplex cover.
Figure 1-4-1
(2) Paper misfeed detection
Figure 1-4-2
Paper Jam
MP tray
Paper misfeed location
Paper misfeed message
Face down tray
paper full sensor
Face down tray
paper full sensor
Exit sensor
Exit sensor
Paper
Paper
exit sensor
exit sensor
Paper
exit sensor
Paper
Paper
feed
feed
sensor
sensor
Paper
feed
sensor
Paper
Paper
feed
feed
sensor
sensor
Paper
feed
sensor
Paper
Paper
feed
feed
sensor
sensor
Paper
feed
sensor
Paper
Paper
feed
feed
sensor
sensor
Paper
feed
sensor
Duplex
Duplex
sensor
sensor
Duplex
sensor
Duplex
Duplex
sensor
sensor
Duplex
sensor
Duplex jam
Duplex jam
sensor
sensor
Duplex jam
sensor
Duplex jam
Duplex jam
sensor
sensor
Duplex jam
sensor
Registration
Registration
sensor
sensor
Registration
sensor
Registration
Registration
sensor
sensor
Registration
sensor
Paper
Paper
exit sensor
exit sensor
Paper
exit sensor
35/37 ppm printer (EUR/USA model)
40/42 and 45/47 ppm printer (EUR/USA model)

Kyocera FS-2020D Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Memory type	DDR2
Processor model	PowerPC 440
Maximum internal memory	1152 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	52 dB
Power supply type	220/240 V, 50/60 Hz
Capacity cartridge	12000 sheets
Power consumption (active)	560 W
Recommended monthly print volume	20000 pages
Maximum duty cycle	150.000 pages per month
Number of print cartridges	1
Total input capacity	500 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	9.2 W
Power consumption (PowerSave)	5.7 W
Energy Star Typical Electricity Consumption (TEC)	2.6 kWh/week
Display	LCD
Certification	GS, TüV, CE
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	382 x 394 x 285 mm
