Kyocera FS-2020D Service Manual

2J0/2J1/2J2
1-4-6
6000 Broken fuser heater lamp wire
The temperature does not reach 100
°C/
212
°F after the fuser heater lamp has
been turned on continuously for 30 s.
35/37 ppm printer (EUR/USA model):
The temperature does not rise by 1°C/
1.8
°F after the fuser heater lamp has
been turned on continuously for 5 s dur-
ing printing.
40/42 and 45/47 ppm printers (EUR/USA
model):
The temperature does not rise by 1
°C/
1.8
°F after the fuser heater lamp has
been turned on continuously for 10 s
during warm-up or at standby.
Poor contact in the
fuser thermistor 1
connector termi-
nals.
Reinsert the connector (See page 1-5-22).
Fuser thermistor 1
installed incor-
rectly.
Check and reinstall if necessary (See page
1-5-22).
Thermal cutout
triggered.
Check for continuity. If none, replace the
thermal cutout (See page 1-5-22).
Fuser heater lamp
installed incor-
rectly.
Check and reinstall if necessary (See page
1-5-22).
Broken fuser
heater lamp wire.
Check for continuity. If none, replace the
fuser heater lamp (See page 1-5-17).
6020 Abnormally high fuser thermistor 2
temperature
The temperature of the fuser thermistor
2 detects 240
°C/464°F or more continu-
ously for 3 s.
Shorted fuser ther-
mistor 2.
Measure the resistance. If it is 0 Ω, replace
the fuser thermistor 2 (See page 1-5-22).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
25).
6030 Broken fuser thermistor 2 wire
Input from fuser thermistor 2 is less than
1 (A/D value) for more than 1 s.
Poor contact in the
fuser thermistor 2
connector termi-
nals.
Reinsert the connector (See page 1-5-22).
Broken fuser ther-
mistor 2 wire.
Measure the resistance. If it is ∞ Ω, replace
the fuser thermistor 2 (See page 1-5-22).
Fuser thermistor 2
installed incor-
rectly.
Check and reinstall if necessary (See page
1-5-22).
Thermal cutout
triggered.
Check for continuity. If none, replace the
thermal cutout (See page 1-5-22).
Fuser heater lamp
installed incor-
rectly.
Check and reinstall if necessary (See page
1-5-17).
Broken fuser
heater lamp wire.
Check for continuity. If none, replace the
fuser heater lamp (See page 1-5-17).
6120 Abnormally high fuser thermistor 1
temperature
The temperature of the fuser thermistor
1 detects 240
°C/464°F or more continu-
ously for 3 s.
Shorted fuser ther-
mistor 1.
Measure the resistance. If it is 0 Ω, replace
the fuser thermistor 1 (See page 1-5-22).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
25).
6130 Broken fuser thermistor 1 wire
Input from fuser thermistor 1 is less than
1 (A/D value) for more than 1 s.
Poor contact in the
fuser thermistor 1
connector termi-
nals.
Reinsert the connector (See page 1-5-22).
Broken fuser ther-
mistor 1 wire.
Measure the resistance. If it is ∞ Ω, replace
the fuser thermistor 1 (See page 1-5-22).
Fuser thermistor 1
installed incor-
rectly.
Check and reinstall if necessary (See page
1-5-22).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-2020D Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Memory type	DDR2
Processor model	PowerPC 440
Maximum internal memory	1152 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	52 dB
Power supply type	220/240 V, 50/60 Hz
Capacity cartridge	12000 sheets
Power consumption (active)	560 W
Recommended monthly print volume	20000 pages
Maximum duty cycle	150.000 pages per month
Number of print cartridges	1
Total input capacity	500 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	9.2 W
Power consumption (PowerSave)	5.7 W
Energy Star Typical Electricity Consumption (TEC)	2.6 kWh/week
Display	LCD
Certification	GS, TüV, CE
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	382 x 394 x 285 mm
