Kyocera FS-2020D - Page 67

2J0/2J1/2J2
1-5-9
6. Remove the registration lower roller.
7. Remove the stopper, gear and three bushes
from the registration lower roller.
8. Check or replace the registration upper and
lower roller and refit all the removed parts.
Figure 1-5-11
Registration
lower roller
Bush
Bush
Bush
Gear
Stopper
