2J0/2J1/2J2
1-5-26
11. Remove the cord cover (40/42 and 45/47
ppm printers [EUR/USA model] only).
12. Remove the connector (40/42 and 45/47
ppm printers [EUR/USA model] only).
13. Detach the joint.
14. Remove the six screws and then remove the
DU base.
Figure 1-5-35
DU base
Joint
Connector
Cord cover
Screw
Screw
Screw
Screw
Screw
Screw
