Alphabetical Parts Index
LeeBoy Model 8515D Conveyor Paver7-166
Description Part No. Figure No. Item No.
CSLS, M16x2 x 45mm 1008903 7-1 42
CSSH, 3/8-16 Shoulder Socket 870279 7-24 6
CSSH, 3/8-16 Shoulder Socket 870279 7-25 6
CSSH, 3/8-16 Shoulder Socket 870279 7-26 7
CSSH, 3/8-16 Shoulder Socket 870279 7-27 7
CSSH, 3/8-16 Shoulder Socket 870279 7-30 6
CSSH, 3/8-16 Shoulder Socket 870279 7-31 6
CSSH, 3/8-16 Shoulder Socket 870279 7-32 7
CSSH, 3/8-16 Shoulder Socket 870279 7-33 7
Cutoff (Left) 851153SRV 7-6 22
Cutoff (Right) 851154SRV 7-6 23
Cylinder, Arm Extension 930070 7-48 16
Cylinder, Hopper Lift 840020 7-4 18
Cylinder, Hydraulic, 2.00 x 12.00/30.00 x 1.25 (Left) 851191 7-42 1
Cylinder, Hydraulic, 2.00 x 12.00/30.00 x 1.25 (Right) 851192 7-42 2
Cylinder, Hydraulic, 2.00 x 2.00 x 42.00 x 1.25 981710R 7-51 21
Cylinder, Hydraulic, 2.00 x 2.00 x 42.00 x 1.25 981710R 7-52 18
Cylinder, Hydraulic, 2.00 x 2.00 x 42.00 x 1.25 981710L 7-51 22
-D-
Cylinder, Hydraulic, 2.00 x 2.00 x 42.00 x 1.25 981710L 7-52 19
Cylinder, Hydraulic, 2.00 x 2.00 x 42.00 x 1.25 (Left) 981710L 7-42 3
Cylinder, Hydraulic, 2.00 x 2.00 x 42.00 x 1.25 (Right) 981710R 7-42 4
Cylinder, Hydraulic, 2.00 x 8.00 610110 7-4 3
Cylinder, Hydraulic, 2.75 x 2.00 x 1.125 Rod 983421 7-42 5
Cylinder, Hydraulic, 2.75 x 2.00 x 1.125 Rod 983421 7-51 23
Cylinder, Hydraulic, Track Tensioner 811331 7-1 11
Cylinder, Hydraulic, Track Tensioner 811331 7-2 9
Decal, Auger Extension (Left) 859784 7-60 29
Decal, Auger Extension (Right) 859783 7-61 29
Decal, Certied Emission Engine Installation 1010091 7-19 REF
Decal, CJ-4 Oil Only 1010089 7-19 REF
Decal, Control Panel, Tier 4 1010027 7-19 REF
Decal, Display Panel, 8515 T4F 1009253-06 7-19 17
Decal, Electric Heat 985143 7-38 12
Decal, Electric Heat 985143 7-62 11
Decal, Electric Heat 1011180 7-64 4
Decal, Electric Heat 1011180 7-67 5
Decal, Electric Heat 1011180 7-70 9
Decal, Elite III Dash (Left) 856647 7-60 30
