LeeBoy 8515D - Page 377

7
Alphabetical Parts Index
7-167
Description Part No. Figure No. Item No.
Decal, Elite III Dash (Right) 856648 7-61 30
Decal, Height 851215 7-15 10
Decal, Info, Test Port 1014058 7-8 3
Decal, Thicker/Thinner 1007677-01 7-60 28
Decal, Thicker/Thinner 1007677-01 7-61 28
Decal, Ultra Low Sulfur Fuel Only 1010090 7-19 REF
Deector, Left Side (High Deck) 850038LSRV 7-3 26
Deector, Right Side (High Deck) 850038RSRV 7-3 REF
Door, Engine Access 1009349 7-13 12
Drive Shaft, Conveyor 851116 7-3 8
Dual Grade & Slope 1014915SRV 7-47 REF
Dual Grade Control 1014914SRV 7-47 REF
Dual Joysticks, Control Box, Plus One 1008904SRV 7-9 4
Dual Pilot Operated Check Valve 983643-05 7-17 5
-E-
Ears, Pivot 851210 7-15 5
ECU, Kubota 1009253-24 7-12 10
Elbow, Reducing 1009384-02 7-11 6
Element, Heater, 46", 1000W 1007275SRV 7-51 10
Element, Heater, 46", 1000W 1007275SRV 7-52 7
Element, Heater, Screed, 40” 987890SRV 7-30 9
Element, Heater, Screed, 40” 987890SRV 7-31 9
Element, Heater, Screed, 40” 987890SRV 7-32 11
Element, Heater, Screed, 40” 987890SRV 7-33 11
Element, Heater, Screed, 41" 987890SRV 7-56 5
Element, Heater, Screed, 41" 987890SRV 7-57 5
Element, Heater, Screed, 46” 987886SRV 7-28 12
Element, Heater, Screed, 46” 987886SRV 7-29 9
Element, Heating, 250W/240V, 11” Complete 1015015SRV 7-51 32
Element, Heating, 500W/220V, 30” Long 1011158 7-65 2
Element, Heating, 500W/220V, 30” Long 1011158 7-66 2
Element, Heating, 500W/220V, 30” Long 1011158 7-68 2
Element, Heating, 500W/220V, 30” Long 1011158 7-69 2
Emergency Brake Switch 988924-03SRV 7-19 13
Enclosure, Electric 2 SW, LW Control (Left) 984535L 7-36 2
Enclosure, Electric 2 Switch, Lower Control (Left) 984535L 7-60 1a
Enclosure, Electric 2 Switch, Lower Control (Right) 984535R 7-61 1a
Enclosure, Electric 3 SW, LW Control (Left) 984534L 7-36 2a
Enclosure, Electric 3 Switch, Lower Control (Left) 984534L 7-60 1
