Lenovo ThinkSystem SR645 V3 - Remove a Heat Sink

Figure 69. Process and heat sink components
1 Captive screws (8)
7 Processor contacts
2 Heat sink 8 Processor triangular mark
3 Processor identification label
9 Carrier triangular mark
4 Heat sink triangular mark 10 Processor carrier
5 Screw bolts (6)
11 Processor heat spreader
6 Retention frame triangular mark
•
“Remove a heat sink” on page 108
• “Remove a processor” on page 110
• “Install a processor” on page 111
• “Install a heat sink” on page 113
Remove a heat sink
Use this information to remove a heat sink. This task requires a Torx T20 screwdriver. This procedure must
be executed by a trained technician.
