Figure 118. Power cable routing for RAID flash power module
From To
1 RAID flash power module
1 RAID flash power port on the RAID/HBA adapter
M.2 drive backplane
This section provides cable routing information for the M.2 drives. Your server supports M.2 SATA/NVMe
and M.2 NVMe drive backplanes.
• For the locations of M.2 connectors on the processor board, see
“System-board-assembly connectors”
on page 21
for details.
