Figure 116. Intrusion switch cable routing
From To
1 Intrusion switch cable 1 Intrusion switch connector on the system board
(system board assembly)
RAID flash power modules
Use the section to understand the cable routing for RAID flash power modules.
The following illustration shows the cable routing of the RAID flash power module on the chassis:
